Solar Remote Control swing gate operator - DT
  1.  Easy Self-learning feature
  2.  Commercial power & solar energy power source can be connected at the same time
  3.  Over current immediate stop function
  4.  Adjustment time of fast speed & slow speed
  5.  Adjustment of force during fast speed & slow speed
  6.  Auto Close function with adjustable closing time delay
  7.  Single or dual swing
  8.  Use max up to 50 sets of remote controllers
  9.  Quality assurance: CE and IP66 certificate obtained
  10.  Optional parts: DC24V gate lock, flashing light, photocell, keypad, push button, backup battery


Input Voltage AC 110V-240V
Operating Voltage DC 24V
Electronic Controller Microcontroller based
Safety Detection Over current detection
Safety Barrier Infrared beam senor (optional)
Certification CE / IP66

Model DT3 plus DT3
Max.piston stroke 430 mm 330 mm
Max.length of motor 1240 mm 1036 mm
Max.leaf's weight 400 kg/leaf 350 kg/leaf
Suitable leaf's length 3.5 meters/ leaf 2.5 meters/ leaf
Frame housing Stainless steel /alumnium alloy
Driving method Screw driven piston type
Opening degree 0 to 110 degree
90 degree rotation time 8 to 12 seconds
Temperature -15°C to +55°C
 ISO9001 CE /IC66

Optional Accessories:
Push Button
Wireless Touch Wall Switch
Keypad System
Waterproof Keypad System
Wireless Video Door Phone
Emergency Switch
Electric Lock - DS218
Electric Lock - EK
ABS Plastic Box
Backup Battery
11W Solar Panel
20W Solar Panel
Remote Control
AC Flashing Light
DC Flashing Light
